Forklift Starter - Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid installed on it. When current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is located on the driveshaft and meshes the pinion utilizing the starter ring gear that is found on the engine flywheel.
The solenoid closes the high-current contacts for the starter motor, that starts to turn. When the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this method via the pinion to the flywheel ring gear. The pinion remains engaged, for instance because the operator fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin separately of its driveshaft.
The actions discussed above will stop the engine from driving the starter. This significant step stops the starter from spinning really fast that it will fly apart. Unless adjustments were done, the sprag clutch arrangement would stop using the starter as a generator if it was used in the hybrid scheme discussed prior. Normally a standard starter motor is designed for intermittent utilization which will stop it being used as a generator.
The electrical components are made to work for roughly 30 seconds so as to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are designed to save cost and weight. This is the reason the majority of owner's instruction manuals meant for vehicles recommend the driver to stop for a minimum of 10 seconds right after every ten or fifteen seconds of cranking the engine, whenever trying to start an engine which does not turn over at once.
The overrunning-clutch pinion was introduced onto the marked in the early 1960's. Previous to the 1960's, a Bendix drive was utilized. This particular drive system works on a helically cut driveshaft that has a starter drive pinion placed on it. When the starter motor starts spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, therefore engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.
The development of Bendix drive was developed in the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, developed and introduced in the 1960s. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights within the body of the drive unit. This was better in view of the fact that the average Bendix drive used so as to disengage from the ring as soon as the engine fired, though it did not stay running.
The drive unit if force forward by inertia on the helical shaft when the starter motor is engaged and starts turning. Then the starter motor becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement could be prevented before a successful engine start.
